DIGITAL MULTIMETER DM7502
Non-contact voltage detection
Live line or neutral line distinguish
DC Voltage: 600mV/6V/60V/600V/1000V ±(0.5% +3)
AC Voltage: 6V/60V ±(0.8% +3), 600V/750V ±(1.0% +10)
DC Current: 60μA/60mA/600mA ±(0.8% +3), 10A ±(1.2% +3)
AC Current: 60mA/600mA ±(1.0% +3), 10A ±(1.5% +3)
Resistance: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ ±(0.8% +3), 60MΩ ±(1.0% +30)
Capacitance: 10nF ±(4.0% +30), 100nF/1000nF/10μF/100μF/1000μF ±(4.0% +3), 10mF/100mF ±(5.0% +3)
Frequency: 10Hz/100Hz/1000Hz/10KHz/100KHz/1000KHz/10MHz ±(1.0% +3)
Duty Cycle: 1%~95% ±(2.0% +3)
Diode test
Max/Min and Data Hold
Backlight function
Flashlight function
Low battery indication
Input jack LED indicator
Includes 2pcs LR6 AA batteries
Packed by: Color box
